Hikvision DS-PDC10DM-VG3 Outdoor Directional Dual-Tech Anti-Mask Curtain Detector with EOLR, Slim, IP65

Product image. Check the selected model, lens, colour and package contents before ordering.

Product details

Brand: Hikvision
Model / SKU: DS-PDC10DM-VG3
Category: Alarm

Hikvision · Alarms

Hikvision DS-PDC10DM-VG3 Outdoor Directional Dual-Tech Anti-Mask Curtain Detector with EOLR, Slim, IP65

Model / SKU: DS-PDC10DM-VG3

Hikvision DS-PDC10DM-VG3 Outdoor Directional Dual-Tech Anti-Mask Curtain Detector with EOLR, Slim, IP65. The Hikvision DS-PDC10DM-VG3 outdoor dual-tech curtain detector features motion, microwave detection, and tamper protection. It has a curtain coverage up to 10m with a maximum mounting height of 4m. It is suitable for perimeter protection by setting up a detection curtain along walls or windows. Slim design for window frame installation IP65 weather resistance for outdoor application Active IR anti-masking Automatic sensitivity Selectable EoL resistors for alarm and tamper-proof wiring Directional detection support HIK-PDC10DM-HW Datasheet Detection Performance Detection Method Passive Infrared;Microwave Detection Range Wall Mount：10m Ceiling Mount：6m Detection Angle 5° Detection Zones 32 Detectable Speed 0.2～3m/s Sensitivity Auto White Light Filter 6500lux Microwave Frequency 24GHz(24.15～24.25GHz) Digital Temperature Compensation Support Creep Zone Protection Support Anti-masking Support Feature Digital Processing Support Sealed Optics Support Tamper Protection Front;Rear Directional Detection Support Interface Alarm Output Normally Closed LED Indicator Green(PIR), Red(Microwave), Green+Orange(Mask), Blue(Alarm) Transmission Transmission Method Wired Electrical Characteristics Power Supply 9 to 16 VDC Typical Voltage 12 VDC Power Consumption Maximum current：25mA@12VDC Quiescent current：16mA@12VDC General Operation Temperature -25 °C to 60 °C (-13 °F to 140 °F) Storage Temperature -25 °C to 60 °C (-13 °F to 140 °F) Operation Humidity 10% to 90% IP Rate IP65 Dimension(WxHxD) 29.2mm × 134.4mm × 39.5mm Weight 79g Mounting Height 2 to 4m Mounting Method Wall;Ceiling Application Scenario Indoor,Outdoor Bracket L-shaped adapter included

$84.70

incl. GST · Equipment supply

Price checked 6 September 2026

Collection availability is confirmed after your order. Please wait for your ready-to-collect notice before visiting.

Free click & collect from Lynbrook. Pay online, then wait for your ready-to-collect email.

Visit showroom ↗Collection steps ↗Need shipping? ↗

Ask about this product ↗

At a glance

Alarm accessory

Showroom enquiries & collection

Ask about this model at 12 Stelvio Close, Lynbrook VIC 3975. Monday–Friday, 9am–5pm; Saturday 9 am–1 pm; closed Sunday. Confirm availability and collection arrangements with the showroom before travelling.

Visit our Lynbrook showroom ↗

Installation & compatibility

Equipment supply does not include installation unless expressly included in your confirmed quote. Check exact model numbers, connections and any required accessories with the team before buying. Confirm setup, cabling and the full work included in your property-specific quote.

Plan a compatible alarm setup

Check whether this listing is a kit, panel, detector, keypad or accessory. Bring your existing panel model and a property plan to confirm compatible devices, wired or wireless connections, power and the intended alert path. A shared brand name alone does not establish compatibility.

Explore Hikvision security alarms ↗Compare security alarms ↗Discuss alarm installation and upgrades ↗
